Strol U1 Product Support
1/ QG
| Performance indictors | Detailed parameters | Detailed parameters sub |
|---|---|---|
| Product dimension | 148.5 % 55.2x170.7 cm | 58.5x21.73 x 4.27inch |
| Walking Area | 120 x 420 cm | 47.24 x 16.54 inch |
| Gross weight | 30 KG | 66.14 Lbs |
| Net weight | 25 KG | 55.11 Lbs |
| Maximum load | 120 KG | 264.5 Lbs |
| Minimum speed | 0.5 mph | / |
| Maximum speed | 4 mph | / |
| Rate voltage | 110-120V ~ | / |
| Screen size | 10x5.5 cm | 3.94x2.17 inch |
| Rated power | 2.25 hp | / |
| Suggested age | 14-60 years old | / |
2 / How to video
Faqs
Didn't Power On
1. Exchange the power cable. 2. Check that the single branch wire on the power switch is not disconnected.
The screen displays E6
Please open the motor cover and check that the black and red wires are linked
The belt didn't run after standing up
1.Check if any codes appear on the display； 2、If there is no error code,just a slow running belt, then tighten the running belt
The screen displays E13
Look at the running belt to see if it is stuck
Loss of function of the switch
Check the cable control (with video). If this does not solve the problem, replace the switch and the cable control
Running belt not working
Remove the motor cover to see if the small belt has come off
Noise in the running board
Check where the running board is rubbing and pry it with a screwdriver
The screen displays E12
Try re-plugging the communication cable from the electronic meter to the lower control terminal
